Taper Bore Chain Saw Sprockets

The sizes of taper bore pin drive chain saw sprockets listed below are for use on logging equipment, firewood cutting machines, bundle saws, deck saws, and special application saws. JA bushings are available with bore sizes from 1/2” to 1 1/4” and most standard metric sizes from 12mm to 25mm. SDS bushings are available with bore sizes from 1/2” to 2” and some metric sizes. If you need a special sprocket please call us at 360-264-2141.

We will not be responsible for improper use of this product. Excessive chain speed, improper lubrication, misalignment, or tension of the chain may create a dangerous condition. Protection from the chain, and chips created by cutting near any persons is required for safe operation.

Part No.	Bushing	Pitch	Tooth Count	Description	OD
DS0275	JA	.325	14	14T325TL5	2.67
DS0136	JA	.375	12	12T375TL	2.56
DS0137	JA	.375	13	13T375TL	2.79
DS0138	JA	.375	14	14T375TL	3.03
DS0139	JA	.375	15	15T375TL	3.27
DS0140	JA	.375	16	16T375TL	3.50
DS0141	JA	.375	17	17T375TL	3.74
DS0203	JA	.375	26	26T375TL	5.87
DS0142	JA	.404	11	11T404TL	2.52
DS0143	JA	.404	12	12T404TL	2.77
DS0144	JA	.404	13	13T404TL	3.03
DS0145	JA	.404	14	14T404TL	3.29
DS0146	JA	.404	15	15T404TL	3.54
DS0147	JA	.404	16	16T404TL	3.80
DS0148	JA	.404	17	17T404TL	4.06
DS0152	JA	.500	10	10T5TL	2.82
DS0153	JA	.500	11	11T5TL	3.14
DS0154	JA	.500	12	12T5TL	3.47
DS0155	JA	.500	13	13T5TL	3.79
DS0156	JA	.500	14	14T5TL	4.11
DS0157	JA	.500	15	15T5TL	4.43
DS0158	JA	.500	16	16T5TL	4.75
DS0160	JA	.75	9	9T75TL	3.92
DS0173	JA	.75	11	11T75TL	4.92
DS0221	SDS	.375	24	24T375LTL	5.39
DS0264	SDS	.375	32	32T375LTL	7.28
DS0286	SDS	.375	35	35T375LTL	7.99
DS0278	SDS	.404	17	17T404LTL	4.06
DS0282	SDS	.404	18	18T404LTL	4.32
DS0284	SDS	.404	19	19T404LTL	4.57
DS0220	SDS	.404	20	20T404LTL	4.83
DS0219	SDS	.404	22	22T404LTL	5.34
DS0161	SDS	.75	9	9T75LTL	3.92
